Installation

Examine door where you will install Privaseal. Stand outside the room with the door open and face the hinge. The Privaseal strips will be installed between the hinges.

Install Part A:

Semicircular section installs on door jamb

Before removing peel strip, line up the flat side of Part A with the door jamb, with the adhesive side toward the frame. The semicircular section should be concentric with the hinge. Remove the peel strip and gently press Part A onto the door frame.

Install Part B:

Flat section installs on door edge

Place Part B on the end of the door with the adhesive side facing the door. When the door is open, the inside edge of Part B should be slightly (about 1/16”) past the center of the hinge barrel. Remove peel strip and gently apply Part B to the back edge of door.

Open and close door to check that Parts A & B do not come into contact. When door is open, be sure that the Privaseal completely blocks the visual gap between the door and frame. If a strip needs to be repositioned slightly, the strip can be removed and reapplied. When you are satisfied that the position is correct, apply heavier thumb pressure on strips to seal adhesive.

If you are installing strips on a door with a middle hinge, repeat the installation on the lower half of the door.
